Trident Metal Industries — global sourcing, reliable supply and competitive pricing for pipes, tubes, fittings, flanges, sheets, plates and rods.
Premium alloys designed for extreme environments—high temperatures, severe corrosion, and immense stress.
Austenitic nickel-chromium-based superalloys known for excellent oxidation and corrosion resistance.
| Alloy | UNS | Density (g/cm³) | Tensile (MPa) | Yield (MPa) |
|---|---|---|---|---|
| 600 | N06600 | 8.47 | 550 | 240 |
| 625 | N06625 | 8.44 | 827 | 414 |
| 718 | N07718 | 8.19 | 1375 | 1034 |
Nickel-molybdenum alloys providing remarkable resistance to strong reducing and oxidizing chemicals.
| Alloy | UNS No. | Standard |
|---|---|---|
| Inconel 600 | N06600 | ASTM B166 |
| Inconel 625 | N06625 | ASTM B446 |
| Hastelloy C276 | N10276 | ASTM B574 |
| Monel 400 | N04400 | ASTM B164 |
Nickel-copper alloys offering excellent corrosion resistance in a variety of marine and chemical environments.
| Alloy | UNS No. | Standard |
|---|---|---|
| Inconel 600 | N06600 | ASTM B166 |
| Inconel 625 | N06625 | ASTM B446 |
| Hastelloy C276 | N10276 | ASTM B574 |
| Monel 400 | N04400 | ASTM B164 |
Commercially pure wrought nickel with good mechanical properties and excellent resistance to many corrosives.
| Alloy | UNS No. | Standard |
|---|---|---|
| Inconel 600 | N06600 | ASTM B166 |
| Inconel 625 | N06625 | ASTM B446 |
| Hastelloy C276 | N10276 | ASTM B574 |
| Monel 400 | N04400 | ASTM B164 |
Combining characteristics of austenitic and ferritic steels, offering high strength and localized corrosion resistance.
| Alloy | UNS No. | Standard |
|---|---|---|
| Inconel 600 | N06600 | ASTM B166 |
| Inconel 625 | N06625 | ASTM B446 |
| Hastelloy C276 | N10276 | ASTM B574 |
| Monel 400 | N04400 | ASTM B164 |
Higher chromium, molybdenum and nitrogen content than standard duplex, providing superior strength and pitting resistance.
| Alloy | UNS No. | Standard |
|---|---|---|
| Inconel 600 | N06600 | ASTM B166 |
| Inconel 625 | N06625 | ASTM B446 |
| Hastelloy C276 | N10276 | ASTM B574 |
| Monel 400 | N04400 | ASTM B164 |
Refer to the 3D drawing and standard dimensions table below before placing your order.
Note: Standard forms available in Special Alloy and High Nickel grades.
| Product Form | Size Range | Thickness / Dia Range | Standard Lengths |
|---|---|---|---|
| Seamless Pipes | 1/2" to 12" NB | Sch 10s to Sch 160 | Single / Double Random |
| Welded Pipes | 8" to 36" NB | Sch 10s to Sch 80 | Single / Double Random |
| Sheets & Plates | 1000mm to 2000mm Width | 1mm to 50mm | 2000mm to 6000mm |
| Round Bars | 5mm to 300mm Dia | - | Up to 6000mm |
| Fittings | 1/2" to 24" NB | Sch 10s to Sch 160 | Seamless & Welded |
| Flanges | 1/2" to 24" NB | 150# to 2500# | Blind, Slip-on, Weld Neck |
Standard chemical composition and mechanical property ranges for the nickel-based special alloys supplied by Trident Metal Industries.
| Element | Composition (wt %) |
|---|---|
| Nickel (Ni) | 72.0 min |
| Chromium (Cr) | 14.0 – 17.0 |
| Iron (Fe) | 6.0 – 10.0 |
| Carbon (C) | 0.15 max |
| Manganese (Mn) | 1.0 max |
| Silicon (Si) | 0.5 max |
| Sulphur (S) | 0.015 max |
| Property | Typical Value |
|---|---|
| Tensile Strength | 550 MPa min |
| Yield Strength (0.2% Proof) | 240 MPa min |
| Elongation at Break | 30% min |
| Hardness | ≤ 90 HRB |
| Element | Composition (wt %) |
|---|---|
| Nickel (Ni) | 58.0 min |
| Chromium (Cr) | 20.0 – 23.0 |
| Molybdenum (Mo) | 8.0 – 10.0 |
| Niobium + Tantalum (Nb+Ta) | 3.15 – 4.15 |
| Iron (Fe) | 5.0 max |
| Carbon (C) | 0.10 max |
| Manganese (Mn) | 0.50 max |
| Property | Typical Value |
|---|---|
| Tensile Strength | 827 MPa min |
| Yield Strength (0.2% Proof) | 414 MPa min |
| Elongation at Break | 30% min |
| Hardness | ≤ 220 HB |
| Element | Composition (wt %) |
|---|---|
| Nickel (Ni) | Balance |
| Chromium (Cr) | 14.5 – 16.5 |
| Molybdenum (Mo) | 15.0 – 17.0 |
| Iron (Fe) | 4.0 – 7.0 |
| Tungsten (W) | 3.0 – 4.5 |
| Carbon (C) | 0.01 max |
| Manganese (Mn) | 1.0 max |
| Property | Typical Value |
|---|---|
| Tensile Strength | 690 MPa min |
| Yield Strength (0.2% Proof) | 283 MPa min |
| Elongation at Break | 40% min |
| Hardness | ≤ 100 HRB |
| Element | Composition (wt %) |
|---|---|
| Nickel (Ni) | 63.0 min |
| Copper (Cu) | 28.0 – 34.0 |
| Iron (Fe) | 2.5 max |
| Manganese (Mn) | 2.0 max |
| Carbon (C) | 0.3 max |
| Silicon (Si) | 0.5 max |
| Sulphur (S) | 0.024 max |
| Property | Typical Value |
|---|---|
| Tensile Strength | 483 – 620 MPa (annealed) |
| Yield Strength (0.2% Proof) | 172 – 240 MPa |
| Elongation at Break | 35% min |
| Hardness | ≤ 150 HB |
Send us the product, grade, size and quantity — we will come back with availability, pricing and a despatch date.
